Air Cooled Low Temperature Chiller for Chemical & Pharma Industry

Product Description:

Our Air Cooled Low Temperature Chiller is a high-performance industrial cooling solution specially engineered to achieve and maintain sub-zero temperatures for critical process applications. Designed with advanced refrigeration technology, this chiller delivers precise temperature control in the range of -5C to -40C, making it ideal for industries where consistent low temperature is essential for product quality and process stability.

This system utilizes a robust air-cooled condenser, eliminating the need for a cooling tower and ensuring easy installation with lower operational costs. Equipped with high-efficiency compressors (single stage / cascade system for ultra-low temperatures), specially designed low-temperature heat exchangers, and intelligent PLC-based control, the chiller ensures reliable and energy-efficient performance even under extreme operating conditions.

Our sub-zero chiller is widely used in pharmaceutical, chemical, food processing, and research industries where accurate low-temperature cooling is critical. Built for Indian climatic conditions, the unit offers stable 24/7 operation, minimal maintenance, and long service life. The compact skid-mounted design, user-friendly interface, and heavy-duty construction make it a preferred choice for industrial low-temperature applications.

Key Features:

• Designed for sub-zero cooling (-5C to -40C)
• Air-cooled system (no cooling tower required)
• High-efficiency compressors with cascade option for ultra-low temp
• Precise temperature control with PLC / digital controller
• Energy-efficient operation with optimized refrigeration cycle
• Heavy-duty low-temperature heat exchangers
• Continuous 24/7 industrial operation capability
• Compact design with easy installation
• Low maintenance and long service life

Technical Specifications (Typical Range):

Temperature Range

• -5C to -40C (customizable)

Cooling Type

• Air Cooled

Compressor Type

• Hermetic / Semi-Hermetic
• Single Stage / Cascade System (for below -20C)

Refrigerant

• R404A / R407C / R134a (as per design)

Evaporator

• Coil Type / Plate Type (Low Temp Design)

Condenser

• Air Cooled (Copper Tube + Aluminium Fins)

Control Panel

• PLC / Microprocessor Based with optional HMI

Power Supply

• 415V / 3 Phase / 50 Hz

Safety Controls

• High/Low Pressure Protection
• Compressor Overload Protection
• Phase Failure / Reverse Protection
• Anti-freeze Protection
• Temperature Safety Cutoff

Applications:

• Pharmaceutical Industry (API & formulation cooling)
• Chemical & Process Industry
• Food Processing & Cold Storage
• Dairy & Beverage Industry
• Research Laboratories
• Ice Formation & Brine Cooling Systems

Why Choose Our Low Temperature Chiller:

• Accurate sub-zero temperature control
• Reliable performance in extreme conditions
• Energy-efficient compared to conventional systems
• Designed for Indian ambient temperatures
• Custom-built solutions for specific applications
• Improves product quality & process efficiency
